Minimum tractor power |
50 hp / 37 kW |
hp/kW |
|
Diesel engine power |
75 hp / 56 kW |
hp/kW |
|
Electric motor power |
37 kW / 50 hp |
kW/hp |
|
Hopper dimensions |
3100 x 1550 mm / 10' 2.05'' x 5' 1.02'' |
mm/ft |
|
Width of measuring roller |
630 mm / 24.80'' |
mm/in |
|
Dosing roller max opening |
200 mm / 7.87'' |
mm/in |
|
Chopping chamber diameter |
530 mm / 20.87'' |
mm/in |
|
Hooked steel feeding conveyor width |
2150 x 630 mm / 7' 0.64'' x 24.80'' |
mm/in |
|
Number of hammers |
64 - 96 |
n° |
|
Hammers thickness |
6-12 mm / 0.236-0.472'' |
mm/in |
|
Hammers peripheral speed |
65 |
m/s |
|
Hourly throughoutput |
20 |
m³/h |
|
Overall dimensions |
5700 x 1920 x 2840 mm / 18' 8.41'' x 6' 3.59'' x 9' 3.81'' |
mm/ft |
|
Weight PTO machine (std model) |
2400 kg / 5291 lbs |
kg/lbs |
Pezzolato S7000
S 7000 hammer chopper is a medium/small machine. It is equipped with a rotor with 64 articulated hammers disposed in four rows and a counter-hammers system to adjust the chopping size.
The material to be chopped is introduced (either manually or mechanically) in the large hopper equipped with a closed chains conveying belt with prawls on the bottom and an upper hydraulic dosing roller which crushes and adjusts the passage of the material under the action of the hammers.
These features make this machine ideal for third-party park and garden maintenance operators, for small compost stations and for small ecological areas.
Max Chopping Chamber Diameter 780 mm / 30.71''
Maximum inlet passage 1000 x 350 mm / 3' 3.37'' x 13.78''
Electric/Self-Propelled/PTO
