• Overall length = 3,515 mm
• Overall width = 980/1,350 mm
• Overall width of superstructure = 980 mm
• Overall height above canopy = 2,370mm
• Rear length = 920 mm
• Track width = 750/1,120 mm
• Landing gear length = 1,585 mm
• Landing gear width (dozer blade) = 980/1,350 mm
• Blade height = 270 mm
• Track link width = 230 mm
• Tail swing radius = 920 mm
• Distance between track wheel and guide wheel (centre) = 1,220 mm
• Boom length = 1,810 mm
• Arm length = 1,130 mm
• Bucket capacity = 0.04 cubic meters

• Max. ground level range = 4,000 mm
• Max. excavation depth = 2,360 mm
• Max. vertical range = 3,665 mm
• Max. dumping height = 2,635 mm
• Minute radius of gyration = 1,705 mm
• Max. excavation depth, vertical wall = 2,215 mm
• Min. working machine height. radius of gyration = 2,745 mm

• Operating weight = 1,925 kg

• Model = Yanmar 3TNV80F
• Rated power = 14,6 kW
• Max. torque = 64,7 Nm/1,800 ft/min
• Shift = 1267 cubic cm

• Main pump = 1 Adjustable axial piston pump
• Maximum oil flow = 1 x 48 l/min
• Travel drive = 2 Adjustable axial piston pump
• Rotary gear = 1 Adjustable axial piston pump

• Boom circuit = 270 bar
• Slewing circuit = 162 bar
• Drive circuit = 270 bar
• Pilot Control Circuit = 35 bar

• Swing speed = 10 rpm
• Max. ground speed = 3.8 km/h faster, 2.2 km/h slower
• Max. traction = 15.6kN
• Climbing ability = 30°
• ISO bucket separation force = 15.2 kN
• ISO arm tear = 9.2kN

Tank = 23 l

Engine coolant = 3.8 l

Engine oil = 2 l

Travel drive (each side) = 0.4 l

Hydraulic tank = 21 l
